Product Description

ELK-GW03 is an intelligent PLC, Zigbee, Bluetooth Mesh multi-mode gateway, based on rail-type design, adopts power line carrier communication technology, and integrates PLC-BUS bus protocol, Zigbee, Bluetooth Mesh protocol and Wifi wireless communication protocol. It communicates with Tuya Smart Cloud Platform in wireless or wired mode, and has the advantages of maturity, stability, reliability, easy deployment, high link and low cost.



Product Features

● Support Tuya smart APP, smart life APP and smart voice speaker control;

● Suitable for smart home, smart hotel, smart business and other places;

● In the environment without WiFi and wired network, the device still supports localized control and linkage;

● Support local binding switch to realize various control methods of various devices;

● The network is connected with the electricity, and the transmission distance is super long, and there is no need to consider the problem of wireless signal blocking;

● Ultra-high reliability: 99.8% communication success rate;

●Easy to use: Wired connection or wireless connection can be used for uplink connection, flexible selection according to user needs, the device is quickly and automatically networked without pairing;



Product Mode	ELK-GW03
Product Size	112mm*90mm* 60mm
Product Material	ABS+PC flame retardant material
Product Color	Brown-gray border + black mirror
Power Supply	AC 100~240V
Operating Temperature	0~40℃
Working Humidity	5%~95%RH without condensation
Protocol Interface	PLC-BUS, Zigbee 3.0
Telecommunication	Wi-Fi 2x2 IEEE 802.11b/g/n 2412MHz–2484MHz 1 RJ45, 10/100Mbps auto-adaptive port
Safety Features	Support WPA-PSK/WPA2-PSK/WPA/WPA2/AES 128
Support Platform	Tuya IoT Platform
